| Usable volume max. |
1000 ml |
| Usable volume with disperser tool min. |
300 ml |
| Usable volume without disperser tool min. |
500 ml |
| Working temperature max. |
120 °C |
| Attainable vacuum |
25 mbar |
| Viscosity max. |
100000 mPas |
| Speed range |
10 – 150 rpm |
| Support rod diameter (with integrated fastening on stand) |
16 mm |
| Material in contact with medium |
AISI 316L, 1.4571, borosilicate glass 3.3, PTFE, PEEK, FKM |
| Reactor vessel openings (units/standard) |
2x NS 29/32, 2x NS 14/23 & 2x GL 14 |
| Permissible ON time |
100 % |
| Temperature measurement resolution |
0.1 K |
| Nominal torque |
3 Nm |
| Heat output |
1000 W |
| Cooling medium permissible operating pressure |
1 bar |
| Weighing range max. |
2000 g |
| Weighing resolution |
1 g |
| Speed min (adjustable) |
10 rpm |
| Heating temperature max. |
180 °C |
| Adjustable safety circuit, upper temperature value |
225 °C |
| Adjustable safety circuit, lower temperature value |
47 °C |
| Adjustable safety circuit, upper temperature value deviation |
20 ±K |
| Adjustable safety circuit, lower temperature value deviation |
10 ±K |
| Cooling medium temperature min. |
3 °C |
| Set temperature resolution |
1 ±K |
| Heat control accuracy of medium with sensor |
0.2 ±K |
| Speed deviation |
5 ±rpm |
| Speed display |
TFT |
| Heat control |
TFT |
| Connection for ext. temperature sensor |
PT 100 |
| Stirring element fastening |
special output shaft |
| Torque display |
yes |
| Torque measurement |
trend |
| Timer |
yes |
| Timer display |
TFT |
| Speed control |
1 RPM steps |
| Type of cooling |
flow |
| Temperature display |
yes |
| Working temperature sensor |
PT 100 |
| Safety temperature sensor |
PT1000 |
| Working temperature display |
TFT |
| Safety temperature display |
TFT |
| Display for operation with ext. sensor |
yes |
| Safety cutout |
yes |
| Reversible direction of rotation |
no |
| pH meter interface |
yes |
| pH value display |
TFT |
| Dimensions (W x H x D) |
443 x 360 x 295 mm |
| Weight |
16 kg |
| Permissible ambient temperature |
5 – 40 °C |
| Permissible relative humidity |
80 % |
| Protection class according to DIN EN 60529 |
IP 21 |
| RS 232 interface |
yes |
| USB interface |
yes |
| Analog output |
no |
| Voltage |
230 / 115 V |
| Frequency |
50/60 Hz |
| Power input |
1200 W |
